X52-1.1

X52-1.1

The most compact engine in its class of very low shaft speed engines

The compact design with limited engine width and height makes X52 suitable for slim hull lines and the wide rating field offers optimum propeller speed for different application. Thanks to the engine’s agility, it is the optimum choice for several vessel segments e.g. Handymax tankers and bulk carriers or 1000–1800 TEU feeder container vessels.

Fuel Types

  • D D

Vessel types

  • Tanker
    Tanker
  • Container Vessel
    Container Vessel
  • Bulk Carrier
    Bulk Carrier
  • Multipurpose Vessel
    Multipurpose Vessel
  • Gas Carrier
    Gas Carrier
  • PCTC
    PCTC

  • High reliability

    Based on the X52 with proven reliability

  • Low service costs

    Long Time Between Overhaul

  • Dual-fuel ready

    LNG/Methanol/Ammonia

Engine details

Definitions Download

X52-1.1

IMO Tier II/Tier III (SCR)
Cylinder bore
520mm
Piston stroke
2315mm
Speed
79-105rpm
Mean effective pressure at R1
21bar
Stroke/bore ratio
4.45

Rated power, principal dimensions and weights

Output in kW at
105rpm 79rpm Length A
mm		 Length A *
mm		 Dry mass
tonnes
Cyl. R1 R2 R3 R4
5 9050 6800 6800 5100 5985 6990 217
6 10860 8160 8160 6120 6925 7930 251
7 12670 9520 9520 7140 7865 288
8 14480 10880 10880 8160 8805 323
Output in kW at
105rpm 79rpm
Cyl. R1 R2 R3 R4
5 9050 6800 6800 5100
6 10860 8160 8160 6120
7 12670 9520 9520 7140
8 14480 10880 10880 8160
Cyl. Length A
mm		 Length A *
mm		 Weight
tonnes
5 5985 6990 217
6 6925 7930 251
7 7865 288
8 8805 323

Dimensions
mm

B C D D (iSCR)
3514 1205 8415 8760
F1 F2 F3 G
10350 10350 9800 1910

Brake specific consumption (BSFC) IN g/kWh

Rating point R1 R2 R3 R4
BMEP, bar 21.0 15.8 21.0 15.8
BSFC (G/kWh) Delta Bypass Tuning, 100% power, Tier II 169.8 162.8 169.8 162.8
R1 BSFC (g/kWh), Tier II Power(%)
50 65 75 90 100
Delta Bypass Tuning 163.7 161.5 161.3 164.1 169.8
Low-load Tuning 160.2 158.0 161.3 164.5 170.8

Brake specific consumption (BSFC) IN g/kWh

Rating point R1 R2 R3 R4
BMEP, bar, 21.0 15.8 21.0 15.8
BSFC (G/kWh), Delta Bypass Tuning, 100% power, Tier II 169.8 162.8 169.8 162.8

R1 BSFC (g/kWh), Tier II

Power (%)
50 65 75 90 100
Delta Bypass Tuning 163.7 161.5 161.3 164.1 169.8
Low-load Tuning 160.2 158.0 161.3 164.5 170.8

iSCR available for 5-7 cylinder engines with one TC on exhaust side.

All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.
