X52DF-1.1

X52DF-1.1

Designed for low emissions and high efficiency for gas and bulk carriers, Handymax tankers, feeder container vessels, RoRos and general cargo ships.

WinGD low-pressure dual-fuel technology has been developed to provide a flexible propulsion solution able to run efficiently, reliably and safely with both gas or liquid fuels. The technology is based on the low-pressure gas system concept. This system has a competitive initial investment and fulfils Tier III emission requirements without any external exhaust gas after treatment system. X-DF technology offers future-fuel flexibility with low emissions for cleaner air today.

All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.



Fuel Types

  • LNG LNG

Vessel types

  • Tanker
    Tanker
  • Container Vessel
    Container Vessel
  • Bulk Carrier
    Bulk Carrier
  • Multipurpose Vessel
    Multipurpose Vessel
  • Gas Carrier
    Gas Carrier
  • PCTC
    PCTC
  • High Reliability

    High Reliability

    Well proven design
  • Fuel Flexibility

    Fuel Flexibility

    Operation on gas or diesel fuels
  • Low emissions

    Low emissions

    IMO Tier III compliance in gas mode without after treatment

Engine details

Definitions Download

X52DF-1.1

IMO Tier III in gas mode
Cylinder bore
520mm
Piston stroke
2315mm
Speed
79-105rpm
Mean effective pressure at R1
17.3bar
Stroke/bore ratio
4.45

Rated power, principal dimensions and weights

Output in kW at
105rpm 79rpm Length A
mm		 Length A *
mm		 Dry mass
tonnes
Cyl. R1 R2 R3 R4
5 7450 6200 5600 4650 5985 6990 217
6 8940 7440 6720 5580 6925 7930 251
7 10430 8680 7840 6510 7865 288
8 11920 9920 8960 7440 8805 323
Output in kW at
105rpm 79rpm
Cyl. R1 R2 R3 R4
5 7450 6200 5600 4650
6 8940 7440 6720 5580
7 10430 8680 7840 6510
8 11920 9920 8960 7440
Cyl. Length A
mm		 Length A *
mm		 Weight
tonnes
5 5985 6990 217
6 6925 7930 251
7 7865 288
8 8805 323

Dimensions
mm

B C D
3514 1205 8415
F1 F2 F3 G
10350 10400 9850 1910

Brake specific consumption in gas mode

Rating point R1 R2 R3 R4
BSEC (energy) kJ/kWh 7201 6962 7299 7064
BSGC (gas) g/kWh 142.7 137.7 144.7 139.7
BSPC (pilot fuel) g/kWh 1.5 1.8 1.5 1.8

Brake specific fuel consumption in diesel mode

Rating point R1 R2 R3 R4
BSFC (diesel Tier II) kJ/kWh 184.1 182.1 184.1 182.1

Brake specific consumption in gas mode

Rating point R1 R2 R3 R4
BSEC (energy) 1 kJ/kWh 7201 6962 7299 7064
BSGC (gas) 2 g/kWh 142.7 137.7 144.7 139.7
BSPC (pilot fuel) 3 g/kWh 1.5 1.8 1.5 1.8

Brake specific fuel consumption in diesel mode

Rating point R1 R2 R3 R4
BSFC (diesel Tier II)1 kJ/kWh 184.1 182.1 184.1 182.1

All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.
